2021 DOOSAN DVF 5000/ 5 AXIS VMC/ 18K SPINDLE/ PROBE
Have one to sell?
ConditionUsed
1 available
2021 DOOSAN DVF 5000/ 5 AXIS VMC HEIDENHAIN TNC640 CONTROLLER, 18K RPM, HSK63A SPINDLE
120 TOOL ATC, RENISHAW OMP 600 STRAIN GAUGE SPINDLE PROBE, RENISHAW AXISET CALIBRATION KIT (FOR KINEMATICS), RENISHAW TOOL SETTING PROBE (TOUCH TYPE ON SWIVEL), RENISHAW TRS2 LASER TOOL BREAKAGE SYSTEM, LNS /TURBO, SUPER FINE COMPACT CHIP CONVEYOR, LNS/CHIPBLASTER, 1000PSI 2-10GPM VARIABLE FLOW TSC, AND LNS/MISTBLASTER, 1200CFM MIST COLLECTOR
CUTTING FEED RATE 0.4 - 787 IPM
MAX TABLE CAPACITY 882 LBS
HEIDENHAIN TNC640 CONTROLLER
18K RPM, HSK63A SPINDLE
120 TOOL ATC
RENISHAW OMP 600 STRAIN GAUGE SPINDLE PROBE
RENISHAW AXISET CALIBRATION KIT (FOR KINEMATICS)
RENISHAW TOOL SETTING PROBE (TOUCH TYPE ON SWIVEL)
RENISHAW TRS2 LASER TOOL BREAKAGE SYSTEM
LNS /TURBO, SUPER FINE COMPACT CHIP CONVEYOR
LNS/CHIPBLASTER, 1000PSI 2-10GPM VARIABLE FLOW TSC
LNS/MISTBLASTER, 1200CFM MIST COLLECTOR
2021 DOOSAN DVF 5000/ 5 AXIS VMC HEIDENHAIN TNC640 CONTROLLER, 18K RPM, HSK63A SPINDLE
120 TOOL ATC, RENISHAW OMP 600 STRAIN GAUGE SPINDLE PROBE, RENISHAW AXISET CALIBRATION KIT (FOR KINEMATICS), RENISHAW TOOL SETTING PROBE (TOUCH TYPE ON SWIVEL), RENISHAW TRS2 LASER TOOL BREAKAGE SYSTEM, LNS /TURBO, SUPER FINE COMPACT CHIP CONVEYOR, LNS/CHIPBLASTER, 1000PSI 2-10GPM VARIABLE FLOW TSC, AND LNS/MISTBLASTER, 1200CFM MIST COLLECTOR
Imperial
| X Travel | 24.6" |
| Y Travel | 17.7" |
| Z Travel | 15.7" |
| Spindle Speed | 18000 rpm |
| Tool Capacity (ATC) | 120 |
| Table Size (W) | 19.7" |
| Table Size (L) | 17.7" |
| Main Spindle Motor | 29.5 hp |
| Spindle Taper | HSK 63 |
| 4th Axis Rotary Table Size | 19.7" |
| Coolant Thru | Yes |
| Coolant Thru High Pressure | Yes |
| Hi Pressure Coolant System | 1000 psi |
| Part Probe | Yes |
| Tool Probe/Auto Tool Length Measurement | Yes |
| Rapid Traverse Rates: X Axis Y Axis Z Axis | 1575 IPM/ 1575 IPM/ 1575 IPM/ |
| Control | CNC (HEIDENHAIN TNC 640) |
| Dimensions | 114" X 114" X 87" |
| Weight | 16,534 lbs |
CUTTING FEED RATE 0.4 - 787 IPM
MAX TABLE CAPACITY 882 LBS
HEIDENHAIN TNC640 CONTROLLER
18K RPM, HSK63A SPINDLE
120 TOOL ATC
RENISHAW OMP 600 STRAIN GAUGE SPINDLE PROBE
RENISHAW AXISET CALIBRATION KIT (FOR KINEMATICS)
RENISHAW TOOL SETTING PROBE (TOUCH TYPE ON SWIVEL)
RENISHAW TRS2 LASER TOOL BREAKAGE SYSTEM
LNS /TURBO, SUPER FINE COMPACT CHIP CONVEYOR
LNS/CHIPBLASTER, 1000PSI 2-10GPM VARIABLE FLOW TSC
LNS/MISTBLASTER, 1200CFM MIST COLLECTOR
