MAZAK QTN 450-II /2000 CNC UNIVERSAL TURNING CENTER
Have one to sell?
ConditionUsed
1 available
THIS MAZAK QTN 450 HAS 80" CENTERS, HYDRAULIC STEADY REST, 20" HYDRAULIC CHUCK WITH A 6.5" BORE AND MAZATROL MATRIX CONTROL.
MAZATROL MATRIX NEXUS CONTROL
12.1" COLOR LCD
USB I/F (2-PORT)
LAN PORT
TOOL EYE AUTOMATIC
HIGH-POWER COOLANT (520W/ 59 PSI/ 16 GPM)
OPERATOR DOOR INTERLOCK WITH LOCK-SWITCH
HYDRAULIC PRESSURE INTERLOCK
SPINDLE BORE DIA - 166mm/ 6.5"
PROGRAMMABLE TAILSTOCK
MULTITAP TRANSFORMER
CHIP CONVEYOR SIDE DISPOSAL - 80"/ 2000U
SMW STEADY REST SLU 3.2
THIS MAZAK QTN 450 HAS 80" CENTERS, HYDRAULIC STEADY REST, 20" HYDRAULIC CHUCK WITH A 6.5" BORE AND MAZATROL MATRIX CONTROL.
Imperial
| Max. Swing | 33.27" |
| Max Turning Diameter | 22.835" |
| Spindle Bore/Max Bar Capacity | 6.5"/ |
| Z Travel | 83.5" |
| X Travel | 13.38" |
| Machining Length | 83.55" |
| Chuck Size | 18" |
| Chuck Type | Hydraullic |
| Spindle Motor | 40 hp |
| Spindle Speeds (RPM) | 2000 |
| Spindle Bore/Bar Capacity | 6.5 in |
| Max. Bar Capacity | 4.625" |
| Turret Tool Positions | 12 |
| Tailstock | Yes |
| Chip Conveyor | Yes |
| Steady Rest | Yes |
| Control | CNC (MAZATROL MATRIX NEXUS) |
MAZATROL MATRIX NEXUS CONTROL
12.1" COLOR LCD
USB I/F (2-PORT)
LAN PORT
TOOL EYE AUTOMATIC
HIGH-POWER COOLANT (520W/ 59 PSI/ 16 GPM)
OPERATOR DOOR INTERLOCK WITH LOCK-SWITCH
HYDRAULIC PRESSURE INTERLOCK
SPINDLE BORE DIA - 166mm/ 6.5"
PROGRAMMABLE TAILSTOCK
MULTITAP TRANSFORMER
CHIP CONVEYOR SIDE DISPOSAL - 80"/ 2000U
SMW STEADY REST SLU 3.2
