2017 DMG Mori NLX-2500SY

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
CNC LATHES MULTI AXIS
Manufacturer:
DMG MORI
Model:
NLX 2500SY/ 700 LATHE W/ MILLING, SUB AND Y
Year:
2017
Stock #:
210419
Status:
For Sale

Description

Used DMG Mori NLX-2500SY (2017) CNC Lathe for Sale. This pre-owned DMG Mori CNC lathe is located in Arizona and available to be seen under power for an inspection.

Maximum Swing36.229"920.22 mm
Max Turning Diameter14.01"355.85 mm
Main Spindle Bore/Max Bar Capacity3.58"/3.1"3.58"/3.1"
Maximum Swing Over Cross Slide29.72"754.89 mm
Distance Between Centers28.7"728.98 mm
Maximum Cutting Length27.75"704.85 mm
X-Axis Travel (X1, X2, X3)10.24"10.24"
Z-Axis Travel (Z1, Z2, Z3)31.3"31.3"
Y-Axis Travel (Y1, Y2, Y3)3.9" +/- 2"3.9" +/- 2"
C-Axis Indexing (1, 2)0.0010.001
W-Axis Travel Sub Spindle50.6 in
Main Spindle Chuck Size10"254 mm
Main Spindle Chuck TypeHydraulicHydraulic
Main Spindle Bore Diameter3.58"90.932 mm
Main Spindle Maximum Bar Work3.1"78.74 mm
Main Spindle Speed5,000 RPM5,000 RPM
Main Spindle Horsepower (CONT. /30 MINS)25 / 22 HP25 / 22 HP
Sub Spindle/2nd Spindle Chuck Size66
Sub Spindle/2nd Spindle Bore Size1.7"1.7"
Sub Spindle/2nd Spindle Speed6,000 RPM6,000 RPM
Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS)15 / 10 HP15 / 10 HP
Main & Sub Spindle SynchronizationYesYes
Number of Turrets11
Bar FeedYesYes
Parts CatcherYesYes
Chip ConveyorYesYes
Tool Eye Automatic Front SpindleYesYes
Rapid Traverse, X-Axis11811181
Rapid Traverse, Y-Axis394394
Rapid Traverse, Z-Axis11811181
ControlCNC (M730UM Celos-Ergoline Touch)CNC (M730UM Celos-Ergoline Touch)
Dimensions174" X 93" X 87"174" X 93" X 87"
Weight17,500 LBS17,500 LBS

LNS Barfeeder

Parts Catcher

Automatic Tool Presetter
