MAZAK NEXUS QTN 450MII/1000
Have one to sell?
ConditionUsed
1 available
MAZAK QTN 450M/ 1000 HAS A MAZATROL MATRIX CONTROL, 20" MANUAL CHUCK, REAR CHUCK PREPPED, ATLM, AND CHIP CONVEYOR.
MAZATROL MATRIX CNC CONTROL
AUTOMATIC TOOL SETTER
REAR CHUCK PREP
SPIRAL, EIA 3D COMP, ROTATION,
GEOMETRIC, SCALING, EXT-DATA I/O
THREAD, INVERSE TIME,
AUTO ATLM,
POLAR COORDINATE INPUT
COMPARISON-STOP, G54.1,
SYNC. MILL TAPPING
VARIABLE 600 SETS,
EIA HELICAL TAP, PATTERN CYCLE
TILTED WORK PLANE,
PITCH ERROR COMP
CHIP CONVEYOR
MAZAK QTN 450M/ 1000 HAS A MAZATROL MATRIX CONTROL, 20" MANUAL CHUCK, REAR CHUCK PREPPED, ATLM, AND CHIP CONVEYOR.
Imperial
| Maximum Swing | 33.26" |
| Max Turning Diameter | 22.83" |
| Main Spindle Bore/Max Bar Capacity | 7.12"/ 6.49" |
| Tail Stock/Sub Spindle | Tail Stock |
| Distance Between Centers | 42" |
| Maximum Cutting Length | 40.2" |
| X-Axis Travel (X1, X2, X3) | 12.21 |
| Z-Axis Travel (Z1, Z2, Z3) | 40.12 |
| C-Axis Indexing (1, 2) | .001 Degrees |
| Main Spindle Chuck Size | 20" |
| Main Spindle Chuck Type | Manual |
| Main Spindle Bore Diameter | 7.12" |
| Main Spindle Maximum Bar Work | 7.12" |
| Main Spindle Speed | 2,000 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 40 |
| Rear Chuck Prep | Yes |
| Turret Tool Positions 1, 2 | 12 |
| Turret Rotary Tool Spindle Speed 1, 2 | 2000 |
| Turret Rotary Tool Horse Power 1, 2 | 10 |
| Chip Conveyor | Yes |
| Number of Available Live Tool Holders | 4 |
| Control | CNC (MAZATROL MATRIX) |
| Weight | 26,800 LBS. |
MAZATROL MATRIX CNC CONTROL
AUTOMATIC TOOL SETTER
REAR CHUCK PREP
SPIRAL, EIA 3D COMP, ROTATION,
GEOMETRIC, SCALING, EXT-DATA I/O
THREAD, INVERSE TIME,
AUTO ATLM,
POLAR COORDINATE INPUT
COMPARISON-STOP, G54.1,
SYNC. MILL TAPPING
VARIABLE 600 SETS,
EIA HELICAL TAP, PATTERN CYCLE
TILTED WORK PLANE,
PITCH ERROR COMP
CHIP CONVEYOR
