Mazak HQR-250MSY Twin Turret, Twin Spindle CNC Lathe w/ Chip Conveyor (2021)
CNC LATHES MULTI AXIS
| X-Axis Travel (X1, X2, X3) | 8.2" (Upper Turret) 5.5625" (Lower Turret) |
| Z-Axis Travel (Z1, Z2, Z3) | 29.875" (Upper Turret) 32.125" (Lower Turret) |
| Y-Axis Travel (Y1, Y2, Y3) | 4" [±2"] (Upper Turret) 4" [±2"] (Lower Turret) |
| Main Spindle Chuck Size | 10" |
| Main Spindle Chuck Type | Hydraulic |
| Main Spindle Bore Diameter | 3.58" |
| Main Spindle Maximum Bar Work | 3.15" |
| Main Spindle Speed | 4,000 RPM |
| Sub Spindle/2nd Spindle Chuck Size | 8 |
| Sub Spindle/2nd Spindle Bore Size | 2.99"/ 2.6" |
| Sub Spindle/2nd Spindle Speed | 5,000 RPM |
| Number of Turrets | 2 |
| Turret Tool Positions 1, 2 | 12 |
| Chip Conveyor | Yes |
| Tool Eye Automatic Front Spindle | No |
| Tool Eye Automatic Second Spindle | No |
| Tool Eye Measurement Upper Turret | Yes |
| Tool Eye Measurement Lower Turret | Yes |
| (HQR) Max. Swing Over Upper Turret | 14.6 in |
| (HQR) Max. Swing Over Lower Turret | 12.6 in |
| (HQR) Standard Chuck Dia. Main Spindle (L) | 10" |
| (HQR) Standard Chuck Dia. Second Spindle (R) | 8" |
| (HQR) Distance Between Chuck Jaw Faces (both spindles) | 33.86" |
| Control | CNC (MAZATROL SMOOTH G) |
| Dimensions | 113" L x 105" W x 95" H |
| Weight | 30,000 LBS |
MAZATROL SMOOTHG
19" COLOR LCD TOUCHSCREEN CONTROL
OIL MATIC AUTOMATIC OIL TEMP REGULATOR
ROYAL FILTERMIST UNIT FX900
LNS TURBO CHIP CONVEYOR
HIGH-PRESSURE COOLANT W/ TEMP CONTROL
RE-THREADING FUNCTION
AUTOMATIC TOOL EYE (1ST & 2ND SPINDLE)
TOOLING - SOME NOT PICTURED
