DMG MORI NTX 1000SZM CNC MULTI-TASKING CENTER
CNC LATHES MULTI AXIS
| Maximum Swing | 14.5" |
| Max Turning Diameter | 14.5" |
| Main Spindle Bore/Max Bar Capacity | 2 |
| Tail Stock/Sub Spindle | SUBSPINDLE |
| X-Axis Travel (X1, X2, X3) | 15"/ 6.1" |
| Z-Axis Travel (Z1, Z2, Z3) | 18.1" + 6.1" ATC Travel, 24" |
| Y-Axis Travel (Y1, Y2, Y3) | +/- 4.1" |
| C-Axis Indexing (1, 2) | .0001, .0001 Degree |
| Main Spindle Chuck Type | Collet |
| Main Spindle Bore Diameter | 2" |
| Main Spindle Maximum Bar Work | 2" |
| Main Spindle Speed | 6,000 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 15/ 10 |
| Sub Spindle/2nd Spindle Bore Size | 1 |
| Sub Spindle/2nd Spindle Chuck Type | Collet |
| Sub Spindle/2nd Spindle Speed | 6,000 RPM |
| Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS) | 15/ 10 |
| ATC Magazine Capacity | 38 |
| Number of Turrets | 1 |
| Turret Tool Positions 1, 2 | 10 |
| B-Axis Travel | +/-120 |
| B-Axis Head Indexing | 0.0001 deg |
| B-Axis Milling Spindle Speed | 20000 rpm |
| B-Axis Milling Spindle Horse Power | 12 |
| Bar Feed Interface | YES |
| Chip Conveyor | Yes |
| High Pressure Coolant System (PSI) | 1000 |
| Work Measuring System (Probe) | SET UP FOR IN MACHINE WORK MEASURING RENISHAW OMP 60 (PROBE NOT INCLUDED) |
| 5-AXIS MACHINING PACKAGE | YES |
| Rapid Traverse, X-Axis | 1574.11 |
| Rapid Traverse, Y-Axis | 1574 |
| Rapid Traverse, Z-Axis | 1968.14 |
| Control | CNC (Fanuc 31i-B5) |
| Weight | 19,690 Lbs. |
MORI MSX 711IV FANUC 31IB5 CNC CONTROL
MORI MAPPS IV CONVERSATIONAL PROGRAMMING
CHIP CONVEYOR
SPINDLE ORIENTATION SPDL 1 & SPDL 2
TOOL OFFSETS HEAD 1 240 SETS, HEAD 2 64 SETS
TOOL LIFE MGMT B
CORNER CIRCULAR INTERPOLATION
BACKGROUND EDIT, USB PORT, 3D INTERFERENCE CHECKING FUNCTION
MANUAL TOOL SETTER
RIGID TAPPING ON MILL HEAD
SPINDLE CHUCK AIR BLOW 1 & 2
SET UP FOR IN-MACHINE WORK MEASURING RENISHAW OMP 60 (PROBE NOT INCLUDED)
BARFEED INTERFACE
X, Y, Z, B AXIS MAGNESCALE
POLYGON CUTTING
ADVANCED ETHERNET / IP
ATA FLASH MEMORY CARD
500 STORED PROGRAMS, 640 METERS
FAST DATA SERVER (100BASE-TX)
TOOL OFFSET FOR 5-AXIS MACHINING
AI CONTOUR CONTROL 2 NANO SMOOTHING
600 CUSTOM MACRO VARIABLES
ROBOT INTERFACE, ETHERNET / IP
1000 PSI CHIP BLASTER THROUGH SPINDLE COOLANT
FULL 5-AXIS CONTOURING
7346, 4250 CUTTING HOURS
