2019 MAZAK HQR 200MSY
Have one to sell?
ConditionUsed
1 available
THIS HQR 200MSY IS A TWIN SPINDLE, TWIN TURRET LATHE WITH A SMOOTH CONTROL, 8" BB CHUCK WITH 2.56", BAR CAPACITY, Y AXIS, 213 PSI COOLANT, LNS BARFEEDER, AND A BUNCH OF TOOLING - SEE LIST BELOW.
MAZATROL SMOOTH CONTROL
LNS QUICK LOAD SERVO 80 S2 BAR LOADER
MAZAK HYPER TOOLING LIST:
3 QUICK CHANGE VERTICAL LIVE HEADS
4 QUICK CHANGE HORIZONTAL LIVE HEADS
2 REG.HORIZONTAL LIVE HEADS
9 STICK TOOL HOLDERS
1 DOUBLE-SIDED STICK TOOL HOLDER
5 1.5’’ POCKETS
9 SPINDLE LINERS
QUICK GRIP COLLET ON BOTH SPINDLES
THRU SPINDLE COOLANT ON 2ND SPINDLE ($8000 UPGRADE )
EXTRA FINGERS FOR PART PICK-OFF
EXTRA CHILLER FILTERS
THIS HQR 200MSY IS A TWIN SPINDLE, TWIN TURRET LATHE WITH A SMOOTH CONTROL, 8" BB CHUCK WITH 2.56", BAR CAPACITY, Y AXIS, 213 PSI COOLANT, LNS BARFEEDER, AND A BUNCH OF TOOLING - SEE LIST BELOW.
Imperial
| Maximum Swing | 14.56" |
| Max Turning Diameter | 13.54" |
| Main Spindle Bore/Max Bar Capacity | 2.99/ 2.56 |
| Tail Stock/Sub Spindle | Sub Spindle |
| X-Axis Travel (X1, X2, X3) | 8.2/ 5.5 |
| Z-Axis Travel (Z1, Z2, Z3) | 29.8/ 32.81 |
| Y-Axis Travel (Y1, Y2, Y3) | 4/ 2.75 |
| Main Spindle Chuck Type | Collet |
| Main Spindle Bore Diameter | 3" |
| Main Spindle Maximum Bar Work | 2.56" |
| Main Spindle Speed | 5,000 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 30 |
| Sub Spindle/2nd Spindle Bore Size | 2.99 |
| Sub Spindle/2nd Spindle Chuck Type | Collet |
| Sub Spindle/2nd Spindle Speed | 5,000 RPM |
| Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS) | 30 |
| Main & Sub Spindle Synchronization | Yes |
| Number of Turrets | 2 |
| Turret Tool Positions 1, 2 | 12 |
| B Axis Rotary Tool Spindle Speed | 6000 rpm |
| B-Axis Rotary Tool Spindle Horsepower | 7.5 hp |
| Bar Feed | Yes |
| Chip Conveyor | Yes |
| High Pressure Coolant System (PSI) | 213 |
| (HQR) Standard Chuck Dia. Main Spindle (L) | 8" |
| Control | CNC |
| Dimensions | 137.6" x 103" |
MAZATROL SMOOTH CONTROL
LNS QUICK LOAD SERVO 80 S2 BAR LOADER
MAZAK HYPER TOOLING LIST:
3 QUICK CHANGE VERTICAL LIVE HEADS
4 QUICK CHANGE HORIZONTAL LIVE HEADS
2 REG.HORIZONTAL LIVE HEADS
9 STICK TOOL HOLDERS
1 DOUBLE-SIDED STICK TOOL HOLDER
5 1.5’’ POCKETS
9 SPINDLE LINERS
QUICK GRIP COLLET ON BOTH SPINDLES
THRU SPINDLE COOLANT ON 2ND SPINDLE ($8000 UPGRADE )
EXTRA FINGERS FOR PART PICK-OFF
EXTRA CHILLER FILTERS
