2023 DOOSAN PUMA 4100 XLMC 3-AXIS CNC TURNING CENTER W/FANUC CNC CONTROL
Have one to sell?
ConditionUsed
1 available
2023 DOOSAN PUMA 4100 XLMC 3-AXIS CNC TURNING CENTER W/FANUC CNC CONTROL, W/ LIVE MILLING, SMW STEADY REST, CHIP CONVEYOR, 12 POS TURRET, 21" 3-JAW CHUCK, TAILSTOCK & TOOL PRESETTER.
SPINDLE NOSE A1-15
SPINDLE TORQUE 2432 FT-LBS.
CHUCK WORK WEIGHT 4,409 LBS.
SHAFT WORK WEIGHT 7,936 LBS.
OD TOOL SIZE 1” x 1”
MAXIMUM BORING BAR SIZE 2.4”
TURRET INDEXING TIME 0.25 SEC
TAILSTOCK QUILL DIA. 4.7”
TAILSTOCK STROKE 4.7”
TAILSTOCK BORE TAPER MT#6
TAILSTOCK TRAVEL 120.7”
ELECTRICAL POWER 380V / 3 Ph / 60 Hz ; 94 AMP ; 55 KVA
FANUC 0i-TF SERIES CNC CONTROL
CHUCK 21" 3-JAW SAMCHULLY MH-221 HYDRAULIC
TWO SPEED GEARBOX
12 POSITION TURRET (BTM-75P TYPE)
STEEL BELT CHIP CONVEYOR & CHIP BUCKET
TOOL SETTER (AUTO - RENISHAW)
PROGRAMMABLE HYDRAULIC STEADY REST (SMW MODEL RX4-ZSW MAX SIZE ~ Ø340 mm)
HIGH COOLANT PUMP 100 PSI (7 BAR)
MIST COLLECTOR
OIL SKIMMER
C AXIS: 0.001 DEGREE
TOOLING PACKAGE INCLUDES:
(4) LIVE MILLING TOOLS (STRAIGHT)
(4) STANDARD TURNING TOOL HOLDERS
(1) FIXED LONG BORING TOLDER (100 mm)
USB PORT ON OP PANEL
AICC 200 BLOCK
DATA SERVER 1 GB
HELICAL INTERPOLATION
DN TOOL MONITORING
ALL AVAILABLE MANUALS
2023 DOOSAN PUMA 4100 XLMC 3-AXIS CNC TURNING CENTER W/FANUC CNC CONTROL, W/ LIVE MILLING, SMW STEADY REST, CHIP CONVEYOR, 12 POS TURRET, 21" 3-JAW CHUCK, TAILSTOCK & TOOL PRESETTER.
Imperial
| Maximum Swing | 31.1" |
| Max Turning Diameter | 21.7" |
| Main Spindle Bore/Max Bar Capacity | 7.1"/ 6.5" |
| Tail Stock/Sub Spindle | TailStock |
| Maximum Swing Over Cross Slide | 22" |
| Maximum Cutting Length | 120.7" |
| X-Axis Travel (X1, X2, X3) | 14.3 |
| Z-Axis Travel (Z1, Z2, Z3) | 122.7 |
| C-Axis Indexing (1, 2) | 0.001 Deg. |
| Main Spindle Chuck Size | 21" |
| Main Spindle Chuck Type | Hydraulic |
| Main Spindle Bore Diameter | 7.1" |
| Main Spindle Maximum Bar Work | 6.5" |
| Main Spindle Speed | 1,500 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 50 |
| Turret Rotary Tool Spindle Speed 1, 2 | 4000 |
| Chip Conveyor | Yes |
| Tool Eye Automatic Front Spindle | Yes |
| Control | CNC (FANUC 0i-TF) |
| Dimensions | 263" x 90” x 90” |
| Weight | 26,600 LBS |
SPINDLE NOSE A1-15
SPINDLE TORQUE 2432 FT-LBS.
CHUCK WORK WEIGHT 4,409 LBS.
SHAFT WORK WEIGHT 7,936 LBS.
OD TOOL SIZE 1” x 1”
MAXIMUM BORING BAR SIZE 2.4”
TURRET INDEXING TIME 0.25 SEC
TAILSTOCK QUILL DIA. 4.7”
TAILSTOCK STROKE 4.7”
TAILSTOCK BORE TAPER MT#6
TAILSTOCK TRAVEL 120.7”
ELECTRICAL POWER 380V / 3 Ph / 60 Hz ; 94 AMP ; 55 KVA
FANUC 0i-TF SERIES CNC CONTROL
CHUCK 21" 3-JAW SAMCHULLY MH-221 HYDRAULIC
TWO SPEED GEARBOX
12 POSITION TURRET (BTM-75P TYPE)
STEEL BELT CHIP CONVEYOR & CHIP BUCKET
TOOL SETTER (AUTO - RENISHAW)
PROGRAMMABLE HYDRAULIC STEADY REST (SMW MODEL RX4-ZSW MAX SIZE ~ Ø340 mm)
HIGH COOLANT PUMP 100 PSI (7 BAR)
MIST COLLECTOR
OIL SKIMMER
C AXIS: 0.001 DEGREE
TOOLING PACKAGE INCLUDES:
(4) LIVE MILLING TOOLS (STRAIGHT)
(4) STANDARD TURNING TOOL HOLDERS
(1) FIXED LONG BORING TOLDER (100 mm)
USB PORT ON OP PANEL
AICC 200 BLOCK
DATA SERVER 1 GB
HELICAL INTERPOLATION
DN TOOL MONITORING
ALL AVAILABLE MANUALS
