HAAS VF-2SS VERTICAL MACHINING CENTER
Have one to sell?
ConditionUsed
1 available
THIS HAAS VF 2SS COMES WITH A 12000 RPM/ CAT 40 SPINDLE, RIGID TAP, AND CHIP AUGER.
SPECIFICATIONS:
X-AXIS TRAVEL 30"
Y-AXIS TRAVEL 16"
Z-AXIS TRAVEL 20"
TABLE SIZE 36" X 14"
TABLE LOAD CPACITY 1,500 LBS
SPINDLE NOSE TO TABLE TOP 4" -24"
SPINDLE SPEED 12,000 RPM
SPINDLE TAPER CAT 40
SPINDLE MOTOR 30 HP
RAPID TRAVERSE RATE 1,400 IPM
ATC 24
MAX TOOL DIAMETER 3"
MAX TOOL LENGTH 9"
MACHINE DIMENSIONS 88" X 92" X 118"
MACHINE WEIGHT 8,000 LBS
HAAS CNC CONTROL
PROGRAMMABLE COOLANT
CHIP AUGER
THIS HAAS VF 2SS COMES WITH A 12000 RPM/ CAT 40 SPINDLE, RIGID TAP, AND CHIP AUGER.
Imperial
| X Travel | 30" |
| Y Travel | 16" |
| Z Travel | 20" |
| Spindle Speed | 12000 rpm |
| Tool Capacity (ATC) | 24 |
| Table Size (W) | 14" |
| Table Size (L) | 36" |
| Main Spindle Motor | 30 hp |
| Spindle Taper | CAT 40 |
| Tool Probe/Auto Tool Length Measurement | No |
| Control | CNC |
| Weight | 8000 |
SPECIFICATIONS:
X-AXIS TRAVEL 30"
Y-AXIS TRAVEL 16"
Z-AXIS TRAVEL 20"
TABLE SIZE 36" X 14"
TABLE LOAD CPACITY 1,500 LBS
SPINDLE NOSE TO TABLE TOP 4" -24"
SPINDLE SPEED 12,000 RPM
SPINDLE TAPER CAT 40
SPINDLE MOTOR 30 HP
RAPID TRAVERSE RATE 1,400 IPM
ATC 24
MAX TOOL DIAMETER 3"
MAX TOOL LENGTH 9"
MACHINE DIMENSIONS 88" X 92" X 118"
MACHINE WEIGHT 8,000 LBS
HAAS CNC CONTROL
PROGRAMMABLE COOLANT
CHIP AUGER
