2007 MAZAK QTN 100MY
Have one to sell?
ConditionUsed
1 available
MAZATROL MATRIX NEXUS CONTROL
OMRON TOOL PROBE
LIVE TOOLING
MAZAK MAZATROL NEXUS CNC CONTROL
COOLANT FILTRATION SYSTEM
ATS COLLET CHUCK
TAILSTOCK
AUTOMATIC PARTS CATCHER
WORK LIGHT
CHIP CONVEYOR
Imperial
| Maximum Swing | 21.65" |
| Max Turning Diameter | 11.02" |
| Main Spindle Bore/Max Bar Capacity | 2.4" / 1.75" |
| Tail Stock/Sub Spindle | TAILSTOCK |
| Maximum Cutting Length | 13.15" |
| X-Axis Travel (X1, X2, X3) | 7.25 |
| Z-Axis Travel (Z1, Z2, Z3) | 15.125 |
| Y-Axis Travel (Y1, Y2, Y3) | 4" |
| Main Spindle Chuck Type | Collet |
| Main Spindle Bore Diameter | 2.4" |
| Main Spindle Maximum Bar Work | 1.75" |
| Main Spindle Speed | 6,000 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 15 |
| Turret Tool Positions 1, 2 | 12 |
| Turret Rotary Tool Spindle Speed 1, 2 | 4500 |
| Turret Rotary Tool Horse Power 1, 2 | 7.0 |
| Parts Catcher | Yes |
| Chip Conveyor | Yes |
| Control | CNC (MAZATROL MATRIX NEXUS) |
| Dimensions | 85"L x 65"W x 76"H |
MAZATROL MATRIX NEXUS CONTROL
OMRON TOOL PROBE
LIVE TOOLING
MAZAK MAZATROL NEXUS CNC CONTROL
COOLANT FILTRATION SYSTEM
ATS COLLET CHUCK
TAILSTOCK
AUTOMATIC PARTS CATCHER
WORK LIGHT
CHIP CONVEYOR
