MAZAK QTN 350-II

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
CNC LATHES 2 AXIS
Manufacturer:
MAZAK
Model:
QTN 350-II
Condition:
Good
Year:
2006
Stock #:
210592
Status:
For Sale

Description

THIS QTN 350 COMES WITH A 12" HYDRAULIC CHUCK WITH A 4" BAR CAPACITY, TAILSTOCK AND MAZATROL NEXUS 640T CONTROL.

Max. Swing26.77"679.96 mm
Max Turning Diameter16.5"419.1 mm
Spindle Bore/Max Bar Capacity4.4"/ 4.0"4.4"/ 4.0"
Z Travel26.77"679.96 mm
X Travel8.85"224.79 mm
Machining Length26"660.4 mm
Chuck Size12"304.8 mm
Chuck TypeHydraullicHydraullic
Spindle Motor35 hp
Spindle Speeds (RPM)33003300
Spindle Bore4.4 in
Max. Bar Capacity4"101.6 mm
Turret Tool Positions1212
TailstockYesYes
High Pressure Coolant SystemYESYES
Chip ConveyorYesYes
Chip ConveyorSideSide
Steady RestNoNo
ControlCNC (MAZATROL 640T NEXUS)CNC (MAZATROL 640T NEXUS)
Dimensions168" X 84" x 90"168" X 84" x 90"
Weight16,500 LBS16,500 LBS

MAZATROL 640T NEXUS CONTROL
10.4" COLOR LCD
3.5" FDD UNIT
AUTOMATIC TOOL EYE
HIGH-POWER COOLANT/ 520W - 59 PSI - 16 GPM
12-POSITION TURRET
BOLT-ON STYLE TOOLING
12" CHUCK
PROGRAMMABLE TAILSTOCK
CHIP AUGER
CHIP CONVEYOR - SIDE EXIT
