2020 Mazak Integrex i-200ST Multi-Axis CNC Milling and Turning Center
Have one to sell?
ConditionUsed
1 available
Maximize your production with this Multi-Axis Mazak Integrex i-200ST Milling and Turning Center featuring live tooling, full 5-axis capability, dual spindles, and Mazatrol SmoothX Control! Designed for high-precision machining with a 72-tool ATC, 12k RPM spindles, and an LNS QLS80-S2 Bar Feeder!
MAZAK SUPERFLOW V8M HIGH PRESSURE COOLANT SYSTEM
MAYFRAN CONCEP CHIP CONVEYOR
SYNCHRONIZED HEAD ONE AND TWO
LIVE TOOLING LOWER TURRET
HIGH-PRESSURE COOLANT PSI: 1,000 PSI
CHIP CONVEYOR
RENISHAW PROBE
PARTS PROBE
MIST COLLECTOR
AUTOMATIC TOOL LENGTH MEASUREMENT SYSTEM
BARFEEDER : LNS QLS80-S2
Maximize your production with this Multi-Axis Mazak Integrex i-200ST Milling and Turning Center featuring live tooling, full 5-axis capability, dual spindles, and Mazatrol SmoothX Control! Designed for high-precision machining with a 72-tool ATC, 12k RPM spindles, and an LNS QLS80-S2 Bar Feeder!
Imperial
| Maximum Swing | 25.91" |
| X-Axis Travel (X1, X2, X3) | 24.21/ 9.06 |
| Z-Axis Travel (Z1, Z2, Z3) | 62.40/ 54.65 |
| Y-Axis Travel (Y1, Y2, Y3) | 9.06" |
| C-Axis Indexing (1, 2) | YES |
| W-Axis Travel Sub Spindle | 60.59 in |
| Main Spindle Chuck Size | 8" |
| Main Spindle Chuck Type | Collet |
| Main Spindle Bore Diameter | 3" |
| Main Spindle Maximum Bar Work | 2.56" |
| Main Spindle Speed | 5,000 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 30 |
| Sub Spindle/2nd Spindle Bore Size | 2.56 |
| Sub Spindle/2nd Spindle Chuck Type | Collet |
| Sub Spindle/2nd Spindle Speed | 5,000 RPM |
| Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS) | 30 |
| ATC Magazine Capacity | 72 |
| Turret Rotary Tool Spindle Speed 1, 2 | 12000 |
| B-Axis Head Indexing | 240 deg |
| Bar Feed | Yes |
| Chip Conveyor | Yes |
| Tool Eye Automatic Front Spindle | Yes |
| High Pressure Coolant System (PSI) | 1000 |
| Work Measuring System (Probe) | YES |
| Lower Turret Positions | 9 |
| Control | CNC (MAZATROL SMOOTH X) |
MAZAK SUPERFLOW V8M HIGH PRESSURE COOLANT SYSTEM
MAYFRAN CONCEP CHIP CONVEYOR
SYNCHRONIZED HEAD ONE AND TWO
LIVE TOOLING LOWER TURRET
HIGH-PRESSURE COOLANT PSI: 1,000 PSI
CHIP CONVEYOR
RENISHAW PROBE
PARTS PROBE
MIST COLLECTOR
AUTOMATIC TOOL LENGTH MEASUREMENT SYSTEM
BARFEEDER : LNS QLS80-S2
