2022 DMG MORI NLX-2000SY/ 500

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
CNC LATHES MULTI AXIS
Manufacturer:
DMG MORI
Model:
NLX 2500SY
Condition:
Excellent
Year:
2022
Stock #:
210643
Status:
For Sale

Description

2022 DMG MORI NLX-2000SY/500 CNC Lathe featuring 36" max swing, 10.9" turn diameter, 30/20 HP spindle, sub spindle, 5,000 RPM, CELOS Ergoline control, tooling worth $25K, 300 cut hours. Enhanced with bar feeder, chip conveyor, and more.

Maximum Swing36"914.4 mm
Max Turning Diameter10.9"276.86 mm
Main Spindle Bore/Max Bar Capacity3.5"/ 3.0"3.5"/ 3.0"
Tail Stock/Sub SpindleSub SpindleSub Spindle
Maximum Swing Over Cross Slide29.7"754.38 mm
X-Axis Travel (X1, X2, X3)10.210.2
Z-Axis Travel (Z1, Z2, Z3)31.331.3
Y-Axis Travel (Y1, Y2, Y3)±2.0"±2.0"
Main Spindle Chuck Size10"254 mm
Main Spindle Chuck TypeHydraulicHydraulic
Main Spindle Bore Diameter3.5"88.9 mm
Main Spindle Maximum Bar Work3"76.2 mm
Main Spindle Speed5,000 RPM5,000 RPM
Main Spindle Horsepower (CONT. /30 MINS)30/ 2030/ 20
Sub Spindle/2nd Spindle Chuck Size66
Sub Spindle/2nd Spindle Bore Size22
Sub Spindle/2nd Spindle Chuck TypeHydraulicHydraulic
Sub Spindle/2nd Spindle Speed6,000 RPM6,000 RPM
Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS)15/ 1015/ 10
Number of Turrets11
Turret Tool Positions 1, 21212
Chip ConveyorYesYes
High Pressure Coolant System (PSI)10001000
Rapid Traverse, X-Axis1181.11181.1
Rapid Traverse, Y-Axis393.7393.7
Rapid Traverse, Z-Axis1181.11181.1
ControlCNC (SIEMENS)CNC (SIEMENS)

SIEMENS CONTROL
LIVE TOOLING & Y-AXIS
12-STATION TURRET
MAIN SPINDLE KITAGAWA 10IN.
SUB SPINDLE KITAGAWA 6IN.
TOOL PRESETTER
HIGH-PRESSURE COOLANT SYSTEM
ONLY 531 HOURS
