MAZAK QTN 250MY-II WITH SMOOTH G CONTROL

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
CNC LATHES MULTI AXIS
Manufacturer:
MAZAK
Model:
QTN 250MY
Condition:
Good
Year:
2017
Stock #:
210647
Status:
For Sale

Description

2017 MAZAK QTN 250MY-II with SMOOTH G Control, used CNC lathe, features a max swing of 26.6", 4000 RPM main spindle with hydraulic chuck, 12 turret positions, chip conveyor, and advanced Mazatrol touchscreen. Ideal for precision multi-axis tasks.

Maximum Swing26.6"675.64 mm
Max Turning Diameter14.76"374.9 mm
Main Spindle Bore/Max Bar Capacity3.58"/ 3.0"3.58"/ 3.0"
Tail Stock/Sub SpindleTAILSTOCKTAILSTOCK
Maximum Cutting Length19.85"504.19 mm
X-Axis Travel (X1, X2, X3)9"9"
Z-Axis Travel (Z1, Z2, Z3)22.76"22.76"
Y-Axis Travel (Y1, Y2, Y3)+/- 2"+/- 2"
C-Axis Indexing (1, 2)0.0001 DEGREE INCR0.0001 DEGREE INCR
Main Spindle Chuck Size10"254 mm
Main Spindle Chuck TypeHydraulicHydraulic
Main Spindle Bore Diameter3.58"90.932 mm
Main Spindle Maximum Bar Work3"76.2 mm
Main Spindle Speed4,000 RPM4,000 RPM
Main Spindle Horsepower (CONT. /30 MINS)3535
Turret Tool Positions 1, 21212
Turret TypeVDIVDI
Turret Rotary Tool Spindle Speed 1, 260006000
Turret Rotary Tool Horse Power 1, 21010
Bar FeedNoNo
Parts CatcherNoNo
Chip ConveyorYesYes
Tool Eye Automatic Front SpindleYesYes
High Pressure Coolant System (PSI)213213
Multi Tap TransformerYesYes
ControlCNC (MAZATROL SMOOTH G)CNC (MAZATROL SMOOTH G)

MAZATROL SMOOTHG TOUCH SCREEN CNC CONTROL
HIGH-POWER COOLANT THROUGH TURRET
PROGRAMMABLE TAILSTOCK
AUTOMATIC TOOL LENGTH MEASUREMENT
THREADING OPTION
CHIP CONVEYOR
575V/3PH/60H
