2007 MAZAK SLANT TURN 50 / 2000U

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
CNC LATHES 2 AXIS
Manufacturer:
MAZAK
Model:
SLANT TURN 50 / 2000U
Condition:
Good
Year:
2007
Stock #:
210680
Status:
For Sale

Description

2007 MAZAK SLANT TURN 50/2000U CNC Lathe features a 31.69" max swing, 25.98" turning diameter, 82" Z travel, and a 21" hydraulic Kitagawa chuck. Equipped with a 4.09" spindle bore, chip conveyor, programmable tailstock, and 15-position drum turret.

Max. Swing31.69"804.93 mm
Max Turning Diameter25.98"659.89 mm
Spindle Bore/Max Bar Capacity4.094.09
Z Travel82"2,082.8 mm
X Travel22.64"575.06 mm
Machining Length81"2,057.4 mm
Chuck Size21"533.4 mm
Chuck TypeHydraullicHydraullic
Spindle Motor50 hp
Spindle Speeds (RPM)15001500
Spindle Bore4.09 in
TailstockYesYes
Chip ConveyorYesYes

4.09" SPINDLE BORE
CHIP CONVEYOR
PROGRAMMABLE TAILSTOCK
15 POSITION DRUM TURRET
TOOL EYE
21" KITAGAWA CHUCK
