2022 DMG MORI NLX 2500SY/ 700 LATHE W/ MILLING, SUB AND Y

2022 DMG MORI NLX 2500SY/ 700 LATHE W/ MILLING, SUB AND Y

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
CNC LATHES MULTI AXIS
Manufacturer:
DMG MORI
Model:
NLX 2500SY/ 700 LATHE W/ MILLING, SUB AND Y
Year:
2022
Stock #:
210714
Status:
For Sale

Description

2022 DMG MORI NLX 2500SY/700 CNC Multi-Axis Lathe with milling, sub-spindle, and Y-axis. Highlights include a 10" main spindle, 6" sub spindle, 12-station turret, live tooling, Siemens control, and high-pressure coolant. Low hours, well-equipped.

Maximum Swing36.2"919.48 mm
Max Turning Diameter19.5"495.3 mm
Main Spindle Bore/Max Bar Capacity3.58"/3.1"3.58"/3.1"
Tail Stock/Sub SpindleSub SpindleSub Spindle
Maximum Swing Over Cross Slide29.72"754.89 mm
Distance Between Centers28.7"728.98 mm
Maximum Cutting Length27.75"704.85 mm
X-Axis Travel (X1, X2, X3)10.24"10.24"
Z-Axis Travel (Z1, Z2, Z3)31.3"31.3"
Y-Axis Travel (Y1, Y2, Y3)3.9" +/- 2"3.9" +/- 2"
C-Axis Indexing (1, 2)0.0010.001
W-Axis Travel Sub Spindle28.9 in
Main Spindle Chuck Size10"254 mm
Main Spindle Chuck TypeHydraulicHydraulic
Main Spindle Bore Diameter3.58"90.932 mm
Main Spindle Maximum Bar Work3.1"78.74 mm
Main Spindle Speed4,000 RPM4,000 RPM
Main Spindle Horsepower (CONT. /30 MINS)25 / 22 HP25 / 22 HP
Sub Spindle/2nd Spindle Chuck Size66
Sub Spindle/2nd Spindle Bore Size1.7"1.7"
Sub Spindle/2nd Spindle Chuck TypeHydraulicHydraulic
Sub Spindle/2nd Spindle Speed6,000 RPM6,000 RPM
Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS)15 / 10 HP15 / 10 HP
Main & Sub Spindle SynchronizationYesYes
Number of Turrets11
Turret Rotary Tool Spindle Speed 1, 260006000
Turret Rotary Tool Horse Power 1, 27.57.5
Bar FeedYesYes
Parts CatcherYesYes
Chip ConveyorYesYes
Tool Eye Automatic Front SpindleYesYes
Rapid Traverse, X-Axis11811181
Rapid Traverse, Y-Axis394394
Rapid Traverse, Z-Axis11811181
ControlCNC (SIEMENS)CNC (SIEMENS)
Dimensions174" X 93" X 87"174" X 93" X 87"
Weight17,500 LBS17,500 LBS

SPINDLE NOSE, MAIN SPINDLE - A2-8
SPINDLE NOSE, SUB-SPINDLE - A2-5

SIEMENS CONTROL
LIVE TOOLING
Y AXIS
LOW HOURS
12 STATION TURRET
MAIN SPINDLE KITAGAWA 10"
SUB SPINDLE KITAGAWA 6"
TOOL PRESETTER
HIGH-PRESSURE COOLANT
