2017 DMG Mori NLX-2500SY/ 700
Have one to sell?
ConditionUsed
1 available
2017 DMG Mori NLX-2500SY/700 CNC Lathe with milling, sub, and Y-axis. Max swing: 36.2", turning diameter: 14.4", spindle speed up to 4,000 RPM. Equipped with CELOS touch CNC and high-pressure coolant system. Dimensions: 120"x90"x90".
POWER SOURCE: AC 220 V THREE PHASE 60 HZ
POWER REQUIREMENT: 48 KVA
WEIGHT: 12,084 LBS APPROX
Machine Dims 120" x 90" x 90"
Coolant Pan: 96" x 77" x 24"
Additional Pan: 24" x 24"
M730UM WITH CELOS – ERGOLINE TOUCH CNC CONTROL
SUB SPINDLE
SUB SPINDLE EJECTOR
SERVO-CONTROLLED C AXIS ON BOTH SPINDLES
12 STATION LIVE TOOL TURRET – BMT
Y-AXIS ON THE TURRET
TOOL PRESETTER
BAR FEEDER INTERFACE (NOT USED)
CHIP CONVEYOR
(3) AXIAL & (4) RADIAL LIVE TOOL HOLDERS
2017 DMG Mori NLX-2500SY/700 CNC Lathe with milling, sub, and Y-axis. Max swing: 36.2", turning diameter: 14.4", spindle speed up to 4,000 RPM. Equipped with CELOS touch CNC and high-pressure coolant system. Dimensions: 120"x90"x90".
Imperial
| Maximum Swing | 36.2" |
| Max Turning Diameter | 14.4" |
| Main Spindle Bore/Max Bar Capacity | 3.58"/3.1" |
| Tail Stock/Sub Spindle | Sub Spindle |
| Maximum Swing Over Cross Slide | 29.72" |
| Distance Between Centers | 28.7" |
| Maximum Cutting Length | 27.75" |
| X-Axis Travel (X1, X2, X3) | 10.24" |
| Z-Axis Travel (Z1, Z2, Z3) | 31.3" |
| Y-Axis Travel (Y1, Y2, Y3) | 3.9" (+/- 1.95") |
| C-Axis Indexing (1, 2) | 0.001 |
| W-Axis Travel Sub Spindle | 28.8 in |
| Main Spindle Chuck Size | 10" |
| Main Spindle Chuck Type | Hydraulic |
| Main Spindle Bore Diameter | 3.58" |
| Main Spindle Maximum Bar Work | 3.14" |
| Main Spindle Speed | 4,000 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 35 |
| Sub Spindle/2nd Spindle Chuck Size | 6 |
| Sub Spindle/2nd Spindle Bore Size | 1.7" |
| Sub Spindle/2nd Spindle Chuck Type | Hydraulic |
| Sub Spindle/2nd Spindle Speed | 6,000 RPM |
| Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS) | 15 / 10 HP |
| Main & Sub Spindle Synchronization | Yes |
| Number of Turrets | 1 |
| Turret Tool Positions 1, 2 | 12 |
| Turret Rotary Tool Spindle Speed 1, 2 | 10000 |
| Turret Rotary Tool Horse Power 1, 2 | 7.0 |
| Bar Feed Interface | YES |
| Parts Catcher | Yes |
| Chip Conveyor | Yes |
| Tool Eye Automatic Front Spindle | Yes |
| High Pressure Coolant System (PSI) | 1000 |
| Rapid Traverse, X-Axis | 1181 |
| Rapid Traverse, Y-Axis | 394 |
| Rapid Traverse, Z-Axis | 1181 |
| Control | CNC (M730UM Celos-Ergoline Touch) |
| Dimensions | 131.8″ X 82.9″ X 86.8″ |
| Weight | 17,500 LBS |
POWER SOURCE: AC 220 V THREE PHASE 60 HZ
POWER REQUIREMENT: 48 KVA
WEIGHT: 12,084 LBS APPROX
Machine Dims 120" x 90" x 90"
Coolant Pan: 96" x 77" x 24"
Additional Pan: 24" x 24"
M730UM WITH CELOS – ERGOLINE TOUCH CNC CONTROL
SUB SPINDLE
SUB SPINDLE EJECTOR
SERVO-CONTROLLED C AXIS ON BOTH SPINDLES
12 STATION LIVE TOOL TURRET – BMT
Y-AXIS ON THE TURRET
TOOL PRESETTER
BAR FEEDER INTERFACE (NOT USED)
CHIP CONVEYOR
(3) AXIAL & (4) RADIAL LIVE TOOL HOLDERS
