UMC-750SS Super-Speed 5-Axis Vertical Machining Center;
Have one to sell?
ConditionUsed
1 available
UMC-750SS 5-Axis Vertical Machining Center by HAAS. 2017 model, used condition. Features: 30" x 20" x 20" travel, 15,000 RPM spindle, 40-tool capacity, integrated 2-axis rotary table, high-speed machining, probing system. Must move immediately.
HAAS CNC CONTROL
500 MM INTEGRATED HIGH-SPEED 2-AXIS TRUNNION ROTARY TABLE
CAT 40 TAPER
30 HP (22.4 KW) VECTOR DRIVE
15,000 RPM, IN LINE DIRECT-DRIVE
HLGH-SPEED 40+1 SIDE MOUNT TOOL CHANGER
1200 IPM (30.5 M/MIN) RAPIDS
HIGH-SPEED MACHINING
SPINDLE ORIENTATION
MACROS
COORDINATE ROTATION & SCALING
WIRELESS INTUITIVE PROBING SYSTEM
SECOND HOME BUTTON
COLOR REMOTE JOG HANDLE
POWER-FAILURE DETECTION MODULE
1 GB EXPANDED MEMORY
1511A COLOR LCD MONITOR
USB PORT, MEMORY LOCK KEY SWITCH,
RIGID TAPPING
75-GALLON (284 LITER) FLOOD COOLANT SYSTEM
BELT-TYPE CHIP CONVEYOR
PROGRAMMABLE COOLANT NOZZLE. COOLANT SYSTEM IS REQUIRED.
THROUGH-SPINDLE COOLANT, 300 PSI (21 BAR)
UMC-750SS 5-Axis Vertical Machining Center by HAAS. 2017 model, used condition. Features: 30" x 20" x 20" travel, 15,000 RPM spindle, 40-tool capacity, integrated 2-axis rotary table, high-speed machining, probing system. Must move immediately.
Imperial
| X Travel | 30 |
| Y Travel | 20 |
| Z Travel | 20 |
| Spindle Speed | 15,000 RPM |
| Tool Capacity (ATC) | 40 |
| Table Size (W) | 19.0 |
| Table Size (L) | 24.0 |
| Main Spindle Motor | 30 |
| Spindle Taper | CAT 40 |
| 5 Axis Programmable Axis's | Full 5 Axis's Contouring |
| Coolant Thru High Pressure | Yes |
| Hi Pressure Coolant System | 300 psi |
| Part Probe | Yes |
| Tool Probe/Auto Tool Length Measurement | Yes |
| Control | CNC (HAAS CNC CONTROL) |
HAAS CNC CONTROL
500 MM INTEGRATED HIGH-SPEED 2-AXIS TRUNNION ROTARY TABLE
CAT 40 TAPER
30 HP (22.4 KW) VECTOR DRIVE
15,000 RPM, IN LINE DIRECT-DRIVE
HLGH-SPEED 40+1 SIDE MOUNT TOOL CHANGER
1200 IPM (30.5 M/MIN) RAPIDS
HIGH-SPEED MACHINING
SPINDLE ORIENTATION
MACROS
COORDINATE ROTATION & SCALING
WIRELESS INTUITIVE PROBING SYSTEM
SECOND HOME BUTTON
COLOR REMOTE JOG HANDLE
POWER-FAILURE DETECTION MODULE
1 GB EXPANDED MEMORY
1511A COLOR LCD MONITOR
USB PORT, MEMORY LOCK KEY SWITCH,
RIGID TAPPING
75-GALLON (284 LITER) FLOOD COOLANT SYSTEM
BELT-TYPE CHIP CONVEYOR
PROGRAMMABLE COOLANT NOZZLE. COOLANT SYSTEM IS REQUIRED.
THROUGH-SPINDLE COOLANT, 300 PSI (21 BAR)
