| Maximum Swing | 36.229" | 920.22 mm |
| Max Turning Diameter | 14.01" | 355.85 mm |
| Main Spindle Bore/Max Bar Capacity | 3.58"/3.1" | 3.58"/3.1" |
| Maximum Swing Over Cross Slide | 29.72" | 754.89 mm |
| Distance Between Centers | 28.7" | 728.98 mm |
| Maximum Cutting Length | 27.75" | 704.85 mm |
| X-Axis Travel (X1, X2, X3) | 10.24" | 10.24" |
| Z-Axis Travel (Z1, Z2, Z3) | 31.3" | 31.3" |
| Y-Axis Travel (Y1, Y2, Y3) | 3.9" +/- 2" | 3.9" +/- 2" |
| C-Axis Indexing (1, 2) | 0.001 | 0.001 |
| W-Axis Travel Sub Spindle | 50.6 in | |
| Main Spindle Chuck Size | 10" | 254 mm |
| Main Spindle Chuck Type | Hydraulic | Hydraulic |
| Main Spindle Bore Diameter | 3.58" | 90.932 mm |
| Main Spindle Maximum Bar Work | 3.1" | 78.74 mm |
| Main Spindle Speed | 5,000 RPM | 5,000 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 25 / 22 HP | 25 / 22 HP |
| Sub Spindle/2nd Spindle Chuck Size | 6 | 6 |
| Sub Spindle/2nd Spindle Bore Size | 1.7" | 1.7" |
| Sub Spindle/2nd Spindle Speed | 6,000 RPM | 6,000 RPM |
| Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS) | 15 / 10 HP | 15 / 10 HP |
| Main & Sub Spindle Synchronization | Yes | Yes |
| Number of Turrets | 1 | 1 |
| Bar Feed | Yes | Yes |
| Parts Catcher | Yes | Yes |
| Chip Conveyor | Yes | Yes |
| Tool Eye Automatic Front Spindle | Yes | Yes |
| Rapid Traverse, X-Axis | 1181 | 1181 |
| Rapid Traverse, Y-Axis | 394 | 394 |
| Rapid Traverse, Z-Axis | 1181 | 1181 |
| Control | CNC (CELOS M730UM/MAPPS V) | CNC (CELOS M730UM/MAPPS V) |
| Dimensions | 174" X 93" X 87" | 174" X 93" X 87" |
| Weight | 17,500 LBS | 17,500 LBS |
Chuck Size
10"
Bar Capacity
3.15"
Swing
36.2"
Turning Diameter
14.41"
Spindle Speed
4,000 RPM
Control
M730UM Celos-Ergoline Touch
Distance Between Centers
28.9"
Turret
12 Station
Live Tooling
C-Axis Live Tooling, Y-Axis
Chip Removal
Chip Conveyor
Sub-Spindle
6" Chuck
