2022 MAZAK QT EZ 10MY With "Y" Axis Live Tooling/ 1700 CUT HOURS!

2022 MAZAK QT EZ 10MY With "Y" Axis Live Tooling/ 1700 CUT HOURS!

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
CNC LATHES MULTI AXIS
Manufacturer:
MAZAK
Model:
QT EZ 10MY
Condition:
Excellent
Year:
2022
Stock #:
211033
Status:
For Sale

Description

2022 MAZAK QT EZ 10MY CNC Lathe, used with 1700 cut hours. Features Y-axis live tooling, MAZATROL SMOOTH EZ, programmable tailstock, hydraulic chuck, and automatic tool presetter. Enjoy 4200 RPM speed and a powerful coolant system.

Maximum Swing21.45"544.83 mm
Max Turning Diameter16.53"419.86 mm
Main Spindle Bore/Max Bar Capacity3.58"/ 2.99"3.58"/ 2.99"
Tail Stock/Sub SpindleTAILSTOCKTAILSTOCK
Maximum Cutting Length22.05"560.07 mm
X-Axis Travel (X1, X2, X3)8.5"8.5"
Z-Axis Travel (Z1, Z2, Z3)23.75"23.75"
Y-Axis Travel (Y1, Y2, Y3)4.0"4.0"
Main Spindle Chuck Size10"254 mm
Main Spindle Chuck TypeHydraulicHydraulic
Main Spindle Bore Diameter3.58"90.932 mm
Main Spindle Maximum Bar Work2.99"75.946 mm
Main Spindle Speed4,200 RPM4,200 RPM
Main Spindle Horsepower (CONT. /30 MINS)2020
Number of Turrets11
Turret Tool Positions 1, 21212
Turret Rotary Tool Spindle Speed 1, 260006000
Turret Rotary Tool Horse Power 1, 27.07.0
Chip ConveyorYesYes
Tool Eye Automatic Front SpindleYesYes
Number of Available Live Tool Holders66
ControlCNC (MAZATROL SMOOTH EZ)CNC (MAZATROL SMOOTH EZ)
Dimensions109.1" x 75" x 67.9"109.1" x 75" x 67.9"
Weight12,000 LBS12,000 LBS

MAZATROL SMOOTH EZ
PROGRAMMABLE TAILSTOCK
COOLANT SYSTEM
AUTOMATIC TOOL PRESETTER (TOOL EYE)
CHIP CONVEYOR
***ONLY 1700 CUT HOURS!***
