2018 NAKAMURA-TOME SC-300 II LMYS

SPECIFICATIONS:

SWING OVER BED 22.05"
TURNING DIAMETER 13.7"
TURNING LENGTH 43.31"
DISTANCE BETWEEN SPINDLES 51.57"
CHUCK SIZE 1 12"
SPINDLE NOSE 1 A2 -8
SPINDLE BORE DIAMETER 1 4.1"
BAR CAPACITY 1 3.5"
SPINDLE SPEEDS 1 3,500 RPM
SPINDLE HORSEPOWER 1 30 hp
CHUCK SIZE 2 8"
SPINDLE NOSE 2 A2 -5
SPINDLE SPEEDS 2 5,000 RPM
SPINDLE HORSEPOWER 2 20 hp
X1 - AXIS TRAVEL 8.76"
Z1 - AXIS TRAVEL 44.69"
Y1 - AXIS TRAVEL 3.2"
C - AXIS INDEXING 1 0.001
C - AXIS INDEXING 2 0.002
W - AXIS TRAVEL SUB SPINDLE 47.75"
RAPID TRAVERSE RATE - X1 629 ipm
RAPID TRAVERSE RATE - Z1 786 ipm
RAPID TRAVERSE RATE - Y1 394 ipm
TURRET TOOL POSITIONS 1 12 station
TURRET ROTARY TOOL SPEEDS 1 6,000 RPM
TURRET ROTARY TOOL
HORSE POWER 1 10 hp
MACHINE WEIGHT 25,000 lb
CONTROL CNC
WEIGHT 10230.00
