CNC VTL & Boring Mills
VTL VERT. LIVE SPINDLE CNC
Olympia V60 LS CNC Vertical Turning Center - Live Tool C Axis VTL (1997)

Olympia V60 LS CNC Vertical Turning Center - Live Tool C Axis VTL (1997)

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
VTL VERT. LIVE SPINDLE CNC
Manufacturer:
OLYMPIA
Model:
V60 LS
Condition:
Very Good
Year:
1997
Stock #:
211074
Status:
For Sale

Description

Olympia V60 LS CNC Vertical Turning Center (1997) with 60" table, 80" max swing, and 62" turning height. Features FANUC 18T control, 12-station ATC (6 + 6 LIVE, 360,000-position C-axis, and chip conveyor.

Table Dia60"1,524 mm
Maximum Swing80"2,032 mm
Maximum Turning Diameter80"2,032 mm
Maximum Turning Height6262
Table Weight Capacity65,000 lb29,483.5 kg
Vertical Travel of Ram, Z-Axis39.4"1,000.8 mm
Horizontal Railhead Travel, X-Axis– 47.2″ / +57.1″– 47.2″ / +57.1″
Cross Rail Vertical Travel39.4"1,000.8 mm
Chuck size6060
Main Table Motor80 HP80 HP
Table RPM450 RPM450 RPM
C-Axis Contouring360,000 Positions360,000 Positions
Cutting Feed Rate394 IPM394 IPM
Automatic Tool Changer12 (6+6 Live Tool)12 (6+6 Live Tool)
Tool ShankCAT 50CAT 50
ControlCNC (FANUC 18T)CNC (FANUC 18T)
Dimensions165″ x 220″ x 215″165″ x 220″ x 215″
Weight75,000 lbs.75,000 lbs.

Ram Size: 8.3″ x 8.3″
Power: 460V – 208v / 3-phase / 60 Htz / 140 kva
Drive Type: Heavy-Duty Gear-Driven Table

FANUC 18T CNC CONTROL
HEAVY TABLE LOAD CAPACITIES
COOLANT TANK
60″ 4-JAW CHUCK
72″ FACEPLATE MOUNTED ON CHUCK
12-STATION AUTOMATIC TOOL CHANGER (6+6 LIVE TOOL)
C-AXIS LIVE TOOL
CAT-50 TAPER MILLING SPINDLE
CHIP CONVEYOR
